155244-5203-RB

Specifications

Özellikler

Keying Slot

RoHS Durumu

RoHS Compliant

Contact Finish Thickness Post

200.0μin 5.08μm

Fastening Type

Latch Lock/Eject Hooks

Contact Shape

Square

Sıra Sayısı

2

Montaj

Through Hole

Contact Plating

Gold

Contact Length Post

0.155 3.94mm

Style

Board to Cable/Wire

Nem Hassasiyeti (MSL)

1 (Unlimited)

Fabrika Tedarik Süresi

8 Weeks

Seri

1552

Lead Pitch

2mm

Contact Materials

Copper Alloy

Yayın Yılı

2007

Current Rating Amps

1.25A

Connector Type

Header

Pitch Mating

0.079 2.00mm

Insulation Color

Black

Insulation Materials

Liquid Crystal Polymer (LCP), Glass Filled

Kurşunsuz

Lead Free

Pitch

2.0066mm

Shrouding

Shrouded - 4 Wall

Insulation Height

0.247 6.28mm

Parça Durumu

Active

Gender

Male

Material Flammability Rating

UL94 V-0

Renk

Black

Ambalaj

Tray

Contact Type

Male Pin

Akım Değeri

1A

Terminal

Solder

Row Spacing Mating

0.079 (2.00mm)

Number Of Contacts

44

Number Of Positions Loaded

All

Contact Finish Mating

Gold

Çalışma Sıcaklığı

-55°C~105°C

Montaj Tipi

Through Hole, Right Angle

Flammability Rating

UL94 V-0
