AZ9571-1C-5DSE

Teknik Özellikler

Release Time

5 ms

Terminal Length

0.0035 inch

Coil Voltagedcmax

10 V

Terminal Kaplaması

Tin

Contact Currentdcmax

1 A

Resistance Coil

167Ω

Relay Type

POWER/SIGNAL RELAY

Operating Temperaturemax

70 °C

Relay Function

SPDT

Reference Standard

UL

Contact Resistance

100 mΩ

Input Switching Control Type

Random

Dielectric Strength Between Open Contacts

400 Vrms

Sealing

EPOXY

Tip

AZ9571-1C-5DSE

Coil Nominal Voltage

5V DC

Max Switching Capacity

30W

Response Time

5ms

Insulation Resistance

100000000 Ω

Coilinput Supply Type

DC

Rohscompliant

Yes

Min Temperature

-30°C

Dielectric Strength Between Coil And Contacts

1000 Vrms

Durability

5 x 10E6

Physical Dimension

12.8mm x 7.8mm x 10.8mm

Electricallife

100000 Cycle(s)

Switching Current Max

1

Rohs Code

Yes

REACH Uyumluluk Kodu

compliant

Contact Voltagedcmax

60 V

Uzunluk

12.50mm

Termination Type

SOLDER

Min Pickup Voltage

4V DC

Body Breadth

7.8 mm

Operating Temperaturemin

-40 °C

End Contact Material

Silver

Contact Materials

AgNi+Au

Yükseklik

10.00mm

Pcb Hole Count

6

Number Of Terminals

6
