AZ832P2-2C-3DE

Teknik Özellikler

Üretici Parça No

AZ832P2-2C-3DE

Pcb Hole Count

10

REACH Uyumluluk Kodu

compliant

Input Switching Control Type

Random

Tip

AZ832P2-2C-3DE

Coil Voltagenom

3 V

Electricallife

100000 Cycle(s)

Contact Voltagedcmax

220 V

Fall Time

3ms

Sealing

EPOXY

Max Switching Capacity

60W

Dielectric Strength Between Coil And Contacts

1500 Vrms

Reference Standard

UL

Terminal Kaplaması

Tin

Dim

(L x W x H) 20.2 x 10 x 10.65 mm

Coil Release Voltagedc

2.25 V

Operating Temperaturemax

85 °C

End Contact Material

Silver

Risk Rank

5.67

Relay Type

POWER/SIGNAL RELAY

Termination Type

SOLDER

Control Mode

bi-stable, 2 coil

Body Height

10.65 mm

Genişlik

10mm

Weight

5 g

Contact Currentdcmax

3 A

Seri

*

Yükseklik

10.65mm

Connections

Solder pins

Contact Resistance

50 mΩ

Content

1pc(s)

JESD-609 Kodu

e3

Release Time

3 ms

Physical Dimension

20.2mm x 10mm x 10.65mm

Response Time

3ms

Terminal Length

0.003 inch

Resistance Coil

45Ω

Part Life Cycle Code

Active

Contact Currentacmax

3 A

Switching Current Max

3A
