AZ6962-1AE-12DE

Teknik Özellikler

Relay Type

POWER/SIGNAL RELAY

Electricallife

100000 Cycle(s)

Max Current Rating

10 A

Durability

1 x 10E7

Max Temperature

+85°C

REACH Uyumluluk Kodu

compliant

Number Of Terminals

5

Min. Çalışma Sıcaklığı

-40 °C

End Contact Material

Silver Tin Oxide

Coil Nominal Voltage

12V DC

Physical Dimension

28.5mm x 10.1mm x 12.5mm

Contact Voltagedcmax

240 V

Contact Materials

AgSnO₂

Insulation Resistance

1000000000 Ω

Contact Currentacmax

10 A

Sealing

EPOXY

Terminal

PC Pin

Pin Sayısı

4

Maks. Çalışma Sıcaklığı

85 °C

Max Pickup Voltage

27.2V DC

Contact Voltageacmax

440 V

Contactoutput Supply Type

AC/DC

Input Switching Control Type

Random

Relay Form

1 FORM A

Min Pickup Voltage

8.4V DC

Paket

Box

Coil Current

19.35 mA

Switching Current Max

10

Response Time

7ms

Coil Voltagedcmax

27.2 V

Terminal Length

0.0035 inch

Body Breadth

10.1 mm

Release Time

3 ms

Body Height

12.5 mm

Max Switching Capacity

300W

ECCN Kodu

EAR99

Body Length Or Diameter

28.5 mm

Uzunluk

28.50mm

Coil Voltage Dc

12 V

Coil Voltagenom

12 V
