82400152

Teknik Özellikler

Clamping Voltage

7.7V

Reach Svhc

Unknown

Uzunluk

1.6mm

Unidirectional Channels

2

Nem Hassasiyeti (MSL)

3 (168 Hours)

Montaj Tipi

Surface Mount

Maks. Çalışma Sıcaklığı

125°C

Terminal

SMD/SMT

Number Of Bidirectional Channels

2

Voltage Reverse Standoff Typ

5V Max

Current Peak Pulse101000s

6A 8/20μs

Tip

Steering (Rail to Rail)

Ambalaj

Tape & Reel (TR)

Applications

General Purpose

Voltage Breakdown Min

6V

RoHS Durumu

ROHS3 Compliant

Max Reverse Leakage Current

5A

Power Line Protection

Yes

Min. Çalışma Sıcaklığı

-40°C

Peak Pulse Current

6A

Kapasitans

2pF

Element Configuration

Dual

Operating Supply Voltage

6V

Test Current

1mA

Max Breakdown Voltage

6V

Direction

Unidirectional

Reverse Standoff Voltage

5V

Max Surge Current

6A

Working Voltage

5V

Genişlik

1.6mm

Seri

WE-TVS

Pin Sayısı

6

Montaj

Surface Mount

Voltage Clamping Max Ipp

7.7V Typ

Breakdown Voltage V

6V

Number Of Channels

2

Tedarikçi Cihaz Paketi

SOT-563

Yükseklik

550μm

Esd Protection

Yes

Kılıf / Paket

SOT-563, SOT-666
