SQJA92EP-T1_GE3

Teknik Özellikler

Turn On Delay Time

15 ns

Drain To Source Voltage Vdss

80 V

Number Of Channels

1

Turn Off Delay Time

24 ns

Power Dissipation

68 W

Yükseklik

1.267 mm

Gate To Source Voltage Vgs

20 V

Min. Çalışma Sıcaklığı

-55 °C

Continuous Drain Current Id

57 A

Max Junction Temperature Tj

175 °C

Maks. Çalışma Sıcaklığı

175 °C

Drain To Source Resistance

7.8 mΩ

Schedule B

8541290080, 8541290080|8541290080|8541290080|8541290080|8541290080

Drain To Source Breakdown Voltage

80 V
