SI1050X-T1-GE3

Teknik Özellikler

Schedule B

8541210080, 8541210080|8541210080|8541210080|8541210080|8541210080

Nominal Vgs

5 V

Rise Time

35 ns

Montaj

Surface Mount

Pin Sayısı

6

Continuous Drain Current Id

1.34 A

Genişlik

1.2 mm

Turn On Delay Time

6.8 ns

Input Capacitance

585 pF

Casepackage

SC

Number Of Channels

1

Maks. Çalışma Sıcaklığı

150 °C

Fall Time

35 ns

Weight

32.006612 mg

Drain To Source Resistance

86 mΩ

Uzunluk

1.7 mm

Turn Off Delay Time

26 ns

Yükseklik

600 µm

Max Power Dissipation

236 mW

Radyasyon Dayanımı

No

Number Of Elements

1

Rds On Max

86 mΩ

RoHS

Compliant

Element Configuration

Single

Drain To Source Voltage Vdss

8 V

Min. Çalışma Sıcaklığı

-55 °C

Gate To Source Voltage Vgs

5 V
