EMZA500ADA100MF61G

Teknik Özellikler

Gerilim

50V

Lead Pitch

1.9mm

Seri

Alchip™- MZA

Kılıf / Paket

Radial, Can - SMD

RoHS Durumu

ROHS3 Compliant

Empedans

880mOhm

Çap

6.3mm

Applications

Automotive

Lifetime Temp

2000 Hrs @ 105°C

Additional Feature

SOLVENT PROOF, RIPPLE CURRENT AND ESR IS MEASURED AT 100KHZ

Tolerans

±20%

JESD-609 Kodu

e6

Reach Svhc

Unknown

Tan Delta

0.1

Montaj

Surface Mount

Ripple Current Ac

165mA

Genişlik

6.6mm

Lead Diameter

800 μm

Life Hours

2000 hours

Capacitor Type

ALUMINUM ELECTROLYTIC CAPACITOR

Parça Durumu

Active

Yükseklik

5.8mm

Maks. Oturma Yüksekliği

0.228 5.80mm

Leakage Current

3μA

Dielectric Material

Aluminium

Terminal Sayısı

2

Ripple Current High Frequency

165mA @ 100kHz

Packing Method

TR

Montaj Tipi

Surface Mount

Terminal Kaplaması

Tin/Bismuth (Sn/Bi)

Nem Hassasiyeti (MSL)

1 (Unlimited)

Boyut / Ölçü

0.248Dia 6.30mm

Ripple Current

165mA

Yayın Yılı

2008

Surface Mount Land Size

0.260Lx0.260W 6.60mmx6.60mm

Terminal Shape

FLAT

Ratings

AEC-Q200

Pin Sayısı

61

Polarization

Polar

Uzunluk

7.2mm
