Adet bazlı fiyat
- 1+ adet$246.59
- 10+ adet$232.63
- 100+ adet$219.47
- 500+ adet$207.04
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Reliability
- COMMERCIAL
- Contact Shape
- Square
- Contact Length Post
- 0.135 3.43mm
- Lifecycle Status
- ACTIVE (Last Updated: 3 days ago)
- Number Of Conductors
- ONE
- Insulation Height
- 0.330 8.38mm
- Sealable
- No
- Elv
- Compliant
- RoHS Durumu
- RoHS Compliant
- Contact Gender
- Male
- Orientation
- Right Angle
- Contact Finish Mating
- Gold
- Shrouding
- Shrouded - 3 Wall
- Contact Type
- Male Pin
- Montaj
- Through Hole
- Body Depth
- 0.77 inch
- Polarization Key
- ENDS
- Lead Length
- 5.461mm
- Contact Finish Thickness Mating
- 50.0μin 1.27μm
- Keyed
- Yes
- ECCN Kodu
- EAR99
- Mixed Contacts
- NO
- Body Breadth
- 0.33 inch
- HTS Kodu
- 8536.69.40.40
- Insulation Materials
- Polyester, Glass Filled
- Din Conformance
- NO
- Fabrika Tedarik Süresi
- 12 Weeks
- Applications
- General Purpose, Military
- Contact Materials
- Brass
- JESD-609 Kodu
- e0
- Iec Conformance
- NO
- Sıra Sayısı
- 2
- Number Of Positions Loaded
- All
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Row Spacing Mating
- 0.100 (2.54mm)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Finish Post
- Tin-Lead
- Mating Post Length
- 3.429mm
- Contact Lengthmating
- 0.181 4.60mm
- Housing Material
- Polyester
