Adet bazlı fiyat
- 1+ adet$6.10
- 10+ adet$5.76
- 100+ adet$5.43
- 500+ adet$5.12
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Uzunluk
- 30.48mm
- Elv
- Compliant
- Frekans
- 4GHz
- Kurşunsuz Kodu
- no
- Body Material
- Brass
- Din Conformance
- NO
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Center Contact Material
- Beryllium Copper
- Nominal Gerilim
- 500V
- Vswr
- 1.3
- Fabrika Tedarik Süresi
- 11 Weeks
- Insertion Loss
- 0.2dB
- Connector Style
- BNC
- Montaj Tipi
- Free Hanging (In-Line)
- Includes
- 3 pcs - 1 Connector, 1 Contact, 1 Ferrule
- Çalışma Sıcaklığı
- -55°C~85°C
- Connector Type
- Jack, Female Socket
- RoHS Durumu
- Non-RoHS Compliant
- Center Contact Plating
- Gold
- Orientation
- Straight
- Sealable
- No
- Mil Conformance
- YES
- Insulation Resistance
- 5GOhm
- Housing Color
- Silver
- Contact Materials
- Copper
- Cable Group
- RG-59, 59A, 59B, 62, 62A, 62B
- Pozisyon Sayısı
- 1
- Ambalaj
- Bulk
- Kurşunsuz
- Not Applicable
- Fastening Type
- Bayonet Lock
- Gender
- Male
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Option
- GENERAL PURPOSE
- Yayın Yılı
- 1998
- Nem Hassasiyeti (MSL)
- Not Applicable
- Insulation Materials
- Polytetrafluoroethylene
- Lifecycle Status
- ACTIVE (Last Updated: 5 days ago)
- Parça Durumu
- Active
- Contact Termination
- Crimp
- Polarity
- Standard
