Adet bazlı fiyat
- 1+ adet$16.58
- 10+ adet$15.64
- 100+ adet$14.76
- 500+ adet$13.92
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Çalışma Sıcaklığı
- -50°C~125°C
- Option
- GENERAL PURPOSE
- Mixed Contacts
- YES
- Uzunluk
- 53.03mm
- Hole Diameter
- 3.048 mm
- Elv
- Non-Compliant
- Reference Standard
- UL, CSA
- Dielectric Material
- Glass
- Filter Feature
- NO
- Wire Gauge Min
- 8 AWG
- Plating
- Cadmium
- Akım Değeri
- 7.5A
- Iec Conformance
- NO
- Number Of Contacts
- 9
- Depth
- 16.68mm
- Montaj Tipi
- Free Hanging (In-Line)
- Contact Arrangement
- S5C4
- Mil Conformance
- NO
- Montaj
- Free Hanging, Panel, Through Hole
- Lifecycle Status
- ACTIVE (Last Updated: 2 days ago)
- Parça Durumu
- Active
- Sealable
- No
- Connector Style
- D-Sub, Combo
- Orientation
- Straight
- RoHS Durumu
- Non-RoHS Compliant
- Shell Size Connector Layout
- 3 DB B - 9W4
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Note
- Contacts Not Included
- Pitch
- 2.54mm
- Housing Material
- Polyester
- Contact Design
- PREASSEM CONN
- Pozisyon Sayısı
- 9 (5 + 4 Coax or Power)
- Shell Material Finish
- Steel, Cadmium Plated
- Shell Material
- Steel
- Yayın Yılı
- 2009
- Connector Type
- Receptacle for Female Contacts
- Contact Style
- Power
- Ambalaj
- Bulk
- Empty Shell
- YES
- Gender
- Female
