2000892-1

Teknik Özellikler

Contact Pattern

RECTANGULAR

Contact Materials

Copper

Number Of Positions Loaded

All

Uzunluk

21.45mm

Nem Hassasiyeti (MSL)

1 (Unlimited)

Max Current Rating

1.5A

Polarization Key

POLARIZED HOUSING

Housing Material

Polymer

Number Of Columns

10

Connector Type

Header, Male Pins

Özellikler

Shielded

Filter Feature

NO

Connector Usage

Daughtercard

Ambalaj

Tray

RoHS Durumu

Non-RoHS Compliant

Montaj Tipi

Board Edge, Through Hole, Right Angle

Material Flammability Rating

UL94 V-0

Pitch

1.4mm

Depth

25.54mm

Flammability Rating

UL94 V-0

Contact Layout Typical

30 Differential Pairs, 30 Ground

Sıra Sayısı

9

Renk

Black

Kılıf / Paket

Module

Contact Finish

Gold

Orientation

Right Angle

Pcb Mounting Orientation

Right Angle

Gender

Male

Number Of Conductors

ONE

Terminal

Press-Fit

Number Of Pcb Rows

9

Shrouding

Partially Shrouded

Pozisyon Sayısı

90

Fabrika Tedarik Süresi

23 Weeks

Çalışma Sıcaklığı

-65°C~125°C

Mixed Contacts

NO

Elv

Non-Compliant

Contact Current Rating

1.5A

Total Number Of Contacts

90

Contact Finish Thickness

50.0μin 1.27μm
