1757826-2

Teknik Özellikler

Orientation

Straight

Yayın Yılı

2009

Contact Design

PREASSEM CONN

Operating Temperature Max

125°C

Gender

Female

Depth

16.84mm

Montaj

Bushing

Sıra Sayısı

3

Mil Conformance

NO

Radyasyon Dayanımı

No

Shell Size Connector Layout

2 DA A High Density

Shell Finish Thickness

200μin 5.08μm

Din Conformance

NO

Body Breadth

0.509 inch

Parça Durumu

Obsolete

Option

GENERAL PURPOSE

RoHS Durumu

RoHS Compliant

Seri

Military, MIL-DTL-24308, AMPLIMITE 90

Montaj Tipi

Free Hanging (In-Line)

Shell Material Finish

Steel, Yellow Chromate Plated Zinc

Iec Conformance

NO

Filter Feature

NO

Hole Diameter

3.05 mm

Total Number Of Contacts

26

Ambalaj

Bulk

Elv

Compliant

Connector Type

Receptacle for Female Contacts

Operating Temperature Min

-55°C

Contact Type

Signal

Fabrika Tedarik Süresi

3 Weeks

Connector Style

D-Sub, High Density

Contact Style

Crimp

ECCN Kodu

EAR99

Reliability

COMMERCIAL

Housing Material

Steel

Mixed Contacts

NO

Pozisyon Sayısı

26

Empty Shell

NO

Note

Contacts Not Included

Plating

Zinc
