Adet bazlı fiyat
- 1+ adet$28.19
- 10+ adet$26.59
- 100+ adet$25.09
- 500+ adet$23.67
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Sealable
- No
- Flange Feature
- Housing/Shell (Unthreaded)
- Mixed Contacts
- NO
- Reliability
- COMMERCIAL
- Çalışma Sıcaklığı
- -50°C~125°C
- Contact Plating
- Gold
- Fabrika Tedarik Süresi
- 10 Weeks
- Plating
- Zinc
- Empty Shell
- YES
- Pozisyon Sayısı
- 78
- Body Material
- Steel
- Seri
- Military, MIL-DTL-24308, AMPLIMITE 90
- Option
- GENERAL PURPOSE
- Parça Durumu
- Active
- Body Breadth
- 0.62 inch
- Insulation Materials
- POLYPHENYLENE SULFIDE
- Elv
- Compliant
- Total Number Of Contacts
- 78
- Hole Diameter
- 3.048 mm
- Iec Conformance
- NO
- Shell Material Finish
- Steel, Yellow Chromate Plated Zinc
- Reach Svhc
- Unknown
- Yayın Yılı
- 2008
- Lifecycle Status
- ACTIVE (Last Updated: 3 days ago)
- Shell Finish Thickness
- 200μin 5.08μm
- Shell Size Connector Layout
- 5 DD D High Density
- Akım Değeri
- 5A
- Uzunluk
- 67.31mm
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mounting Option2
- LOCKING
- ECCN Kodu
- EAR99
- Connector Style
- D-Sub, High Density
- Contact Style
- Crimp
- Genişlik
- 15.75mm
- Note
- Contacts Not Included
- Montaj Tipi
- Free Hanging (In-Line)
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- RoHS Durumu
- Non-RoHS Compliant
- Din Conformance
- NO
