Adet bazlı fiyat
- 1+ adet$10.16
- 10+ adet$9.58
- 100+ adet$9.04
- 500+ adet$8.53
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Flange Feature
- Housing/Shell (Unthreaded)
- Sealable
- No
- Material
- Metal
- Empty Shell
- NO
- Plating
- Zinc
- Pozisyon Sayısı
- 15
- Body Material
- Steel
- Contact Plating
- Gold, Nickel
- Fabrika Tedarik Süresi
- 10 Weeks
- Mixed Contacts
- NO
- Reliability
- COMMERCIAL
- Kurşunsuz
- Lead Free
- Operating Temperature Min
- -55°C
- Elv
- Compliant
- Hole Diameter
- 3.048 mm
- Iec Conformance
- NO
- Shell Material Finish
- Steel, Yellow Chromate Plated Zinc
- Total Number Of Contacts
- 15
- Seri
- Military, MIL-DTL-24308, AMPLIMITE 109
- Option
- GENERAL PURPOSE
- Parça Durumu
- Active
- Body Breadth
- 0.509 inch
- HTS Kodu
- 8536.69.40.30
- Shell Finish Thickness
- 20μin 0.51μm
- Shell Size Connector Layout
- 2 DA A
- Lifecycle Status
- ACTIVE (Last Updated: 3 days ago)
- Montaj
- Panel
- Akım Değeri
- 7.5A
- Reach Svhc
- No SVHC
- Yayın Yılı
- 2007
- Dielectric Material
- Polyester
- Uzunluk
- 39.52mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Note
- Contacts Not Included
- ECCN Kodu
- EAR99
- Connector Style
- D-Sub
- Contact Style
- Crimp
- Genişlik
- 9.52mm
- Contact Type
- Signal
- Connector Type
- Receptacle for Female Contacts
