1-331693-2

Teknik Özellikler

Gender

Male

Polarized

No

Mating Cycles

500

Body Material

Brass

Fastening Type

Bayonet Lock

Option

GENERAL PURPOSE

Insertion Loss

0.2 dB

Center Contact Plating

Gold

Total Number Of Contacts

1

Din Conformance

NO

Insulation Materials

Polytetrafluoroethylene

Çalışma Sıcaklığı

-55°C~85°C

Ambalaj

Bulk

Elv

Compliant

Vswr

1.3

Connector Type

Jack, Female Socket

Center Contact Material

Beryllium Copper

Connector Style

BNC

Yayın Yılı

2005

Empedans

50Ohm

Filter Feature

NO

Number Of Ports

1

Nem Hassasiyeti (MSL)

Not Applicable

Kurşunsuz Kodu

no

Dielectric Material

Polytetrafluoroethylene (PTFE)

Housing Color

Silver

RoHS Durumu

Non-RoHS Compliant

Kurşunsuz

Not Applicable

Mil Conformance

NO

Reliability

COMMERCIAL

Polarity

Standard

Frequencymax

4GHz

Fabrika Tedarik Süresi

3 Weeks

Cable Group

RG-174, 188

Uzunluk

35.71mm

Contact Style

COAX

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Operating Frequency Max

4GHz

Contact Materials

Copper

Nominal Gerilim

500V
