Adet bazlı fiyat
- 1+ adet$42.74
- 10+ adet$40.33
- 100+ adet$38.04
- 500+ adet$35.89
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj
- Panel
- Reliability
- COMMERCIAL
- Empedans
- 50Ohm
- Frekans
- 18GHz
- Center Contact Plating
- Gold
- Number Of Ports
- 1
- Mating Cycles
- 500
- Option
- GENERAL PURPOSE
- Withdrawl Forcemin
- .278 N
- Ambalaj
- Bulk
- Elv
- Compliant
- Fastening Type
- Threaded
- Yayın Yılı
- 2000
- Contact Resistance
- 2mOhm
- Additional Feature
- CAPTIVE CONTACT
- Contact Materials
- Copper
- Özellikler
- Extended Insulation
- Contact Style
- COAX
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Orientation
- Right Angle
- Body Material
- Stainless Steel
- Insulation Resistance
- 10GOhm
- Din Conformance
- NO
- Insulation Materials
- Tetrafluoroethylene
- Depth
- 12.7mm
- Parça Durumu
- Active
- Lifecycle Status
- ACTIVE (Last Updated: 4 days ago)
- Fabrika Tedarik Süresi
- 12 Weeks
- Çalışma Sıcaklığı
- -65°C~125°C
- Pozisyon Sayısı
- 1
- Polarity
- Normal
- Contact Termination
- Solder
- ECCN Kodu
- EAR99
- Housing Color
- Silver
- Connector Style
- SMA
- Connector Type
- Receptacle, Female Socket
- Total Number Of Contacts
- 1
- Center Contact Material
- Beryllium Copper
- RoHS Durumu
- RoHS Compliant
- Radyasyon Dayanımı
- No
