ESH1JM RSG

Teknik Özellikler

Operating Temperature Max

150°C

Current Reverse Leakage Vr

1μA @ 600V

RoHS Durumu

ROHS3 Compliant

Additional Feature

FREE WHEELING DIODE

Ambalaj

Digi-Reel®

Operating Temperature Junction

-55°C~150°C

Terminal Pozisyonu

DUAL

Voltage Forward Vf Max If

1.5V @ 1A

Rep Pk Reverse Voltagemax

600V

Diode Type

Standard

Reverse Recovery Time

25ns

Current Average Rectified Io

1A

Nem Hassasiyeti (MSL)

1 (Unlimited)

Case Connection

CATHODE

Yüzey Montaj

YES

Diode Element Material

SILICON

Jesd30 Code

R-PDSO-F2

Capacitance Vr F

3pF @ 4V 1MHz

Fabrika Tedarik Süresi

14 Weeks

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Voltage Dc Reverse Vr Max

600V

Number Of Elements

1

JESD-609 Kodu

e3

Kılıf / Paket

2-SMD, Flat Lead

Configuration

SINGLE

Montaj Tipi

Surface Mount

Terminal Sayısı

2

Parça Durumu

Active

Terminal Kaplaması

Matte Tin (Sn)

ECCN Kodu

EAR99

Output Currentmax

1A
