NPB02SVFN-RC

Teknik Özellikler

Sıra Sayısı

1

Contact Materials

PHOSPHOR BRONZE

Pozisyon Sayısı

2

Number Of Conductors

ONE

Parça Durumu

Active

Kurşunsuz

Lead Free

Body Breadth

0.049 inch

Body Length Or Diameter

0.098 inch

Contact Style

SQ PIN-SKT

Polarization Key

POLARIZED HOUSING

Yayın Yılı

2010

Nem Hassasiyeti (MSL)

1 (Unlimited)

Total Number Of Contacts

2

Current Rating Amps

1A per Contact

Fabrika Tedarik Süresi

5 Weeks

Contact Finish

Gold

Mounting Option1

LOCKING

Reference Standard

UL

Reliability

COMMERCIAL

Pitch

0.050 1.27mm

Contact Finish Thickness

Flash

Contact Pattern

RECTANGULAR

Number Of Positions Or Pins Grid

2 (1 x 2)

Material Flammability Rating

UL94 V-2

Montaj Stili

STRAIGHT

Housing Material

Polyamide (PA66), Nylon 6/6

Tip

Closed Top, Grip

RoHS Durumu

ROHS3 Compliant

Gender

Female Sockets

Ambalaj

Bulk

Yükseklik

0.217 5.50mm
