STM32L496VGY6TR

Teknik Özellikler

Peripherals

Brown-out Detect/Reset, DMA, LCD, PWM, WDT

Voltage Supply Vccvdd

1.71V~3.6V

Besleme Gerilimi

3V

Maks. Oturma Yüksekliği

0.585mm

Supply Voltagemax Vsup

3.6V

Has Adc

YES

Kılıf / Paket

100-UFBGA, WLCSP

Program Memory Size

1MB 1M x 8

Dac Channels

YES

Romword

1048576

On Chip Program Rom Width

8

Jesd30 Code

R-PBGA-B100

Boundary Scan

YES

Terminal Pozisyonu

BOTTOM

Address Bus Width

26

Ambalaj

Tape & Reel (TR)

Seri

STM32L4

Lifecycle Status

ACTIVE (Last Updated: 7 months ago)

Upsucsperipheral Ics Type

MICROCONTROLLER, RISC

Parça Durumu

Active

Cpu Family

CORTEX-M4

Number Of Timers

13

Montaj Tipi

Surface Mount

Terminal Adımı

0.4mm

On Chip Data Ram Width

8

Temel Parça No

STM32L496

Genişlik

4.142mm

Low Power Mode

YES

Fabrika Tedarik Süresi

12 Weeks

Clock Frequency

48MHz

Speed

80MHz

Core Size

32-Bit

External Data Bus Width

16

Number Of Dma Channels

14

Data Converters

A/D 16x12b; D/A 2x12b

Connectivity

CANbus, EBI/EMI, I2C, IrDA, LINbus, MMC/SD, QSPI, SAI, SPI, SWPMI, UART/USART, USB OTG

Pwm Channels

YES

Terminal Sayısı

100

RoHS Durumu

ROHS3 Compliant

Core Processor

ARM® Cortex®-M4
