STM32L486JGY6TR

Teknik Özellikler

External Data Bus Width

16

Core Size

32-Bit

Number Of Dma Channels

14

Speed

80MHz

Data Converters

A/D 16x12b; D/A 2x12b

Connectivity

CANbus, I2C, IrDA, LINbus, MMC/SD, QSPI, SAI, SPI, SWPMI, UART/USART, USB OTG

Pwm Channels

YES

Ram Size

128K x 8

Number Of External Interrupts

16

Supply Voltagemin Vsup

1.71V

Terminal Formu

BALL

Core Processor

ARM® Cortex®-M4

Terminal Sayısı

72

RoHS Durumu

ROHS3 Compliant

Çalışma Sıcaklığı

-40°C~85°C TA

Oscillator Type

Internal

Nem Hassasiyeti (MSL)

1 (Unlimited)

Program Memory Type

FLASH

Uzunluk

4.4mm

Format

FLOATING-POINT

Yüzey Montaj

YES

Bit Size

32

Dma Channels

YES

Ram Words

32000

Number Of Ios

57

Voltage Supply Vccvdd

1.71V~3.6V

Integrated Cache

YES

Besleme Gerilimi

3V

Maks. Oturma Yüksekliği

0.585mm

Peripherals

Brown-out Detect/Reset, DMA, LCD, PWM, WDT

Supply Voltagemax Vsup

3.6V

On Chip Program Rom Width

8

Kılıf / Paket

72-UFBGA, WLCSP

Has Adc

YES

Program Memory Size

1MB 1M x 8

Dac Channels

YES

Seri

STM32L4

Jesd30 Code

R-PBGA-B72

Boundary Scan

YES

Ambalaj

Tape & Reel (TR)
