SMC30J8.5CA

Teknik Özellikler

Parça Durumu

Active

Number Of Channels

1

Peak Pulse Current

208A

Clamping Voltage

14.4V

Working Voltage

8.5V

Power Line Protection

No

Number Of Elements

1

Seri

SMC30J, TRANSIL™

Terminal Formu

C BEND

Current Peak Pulse101000s

208A

Terminal Pozisyonu

DUAL

Element Configuration

Single

Peak Pulse Power

3kW

Direction

Bidirectional

Tip

Zener

Terminal

SMD/SMT

Diode Element Material

SILICON

Power Peak Pulse

3000W 3kW

Reach Svhc

No SVHC

Kılıf / Paket

DO-214AB, SMC

Montaj Tipi

Surface Mount

ECCN Kodu

EAR99

RoHS Durumu

ROHS3 Compliant

Pin Sayısı

2

Breakdown Voltage V

9.4V

Çalışma Sıcaklığı

-55°C~175°C TJ

Ambalaj

Cut Tape (CT)

Nem Hassasiyeti (MSL)

1 (Unlimited)

Uzunluk

7.15mm

Leakage Current

10μA

Terminal Sayısı

2

Pin Sayısı

2

Nonrep Peak Rev Power Dismax

3000W

Temel Parça No

SMC30J

Voltage Clamping Max Ipp

14.4V

Montaj

Surface Mount

Max Power Dissipation

3kW

Applications

General Purpose

Lifecycle Status

ACTIVE (Last Updated: 6 months ago)

Reverse Standoff Voltage

8.5V
