A41-25-12

Teknik Özellikler

Kapasitans

33 µF

Özellikler

Fail Safe with Built-in Fuse, High Reliability

Tip

Laminated Core

Nominal Input Voltage Ac

480 VAC

Nem Hassasiyeti (MSL)

Not Applicable

Yükseklik

58.7mm

Ihs Manufacturer

SIGNAL TRANSFORMER CO INC

ECCN Kodu

EAR99

Power Max

25VA

Isolation Voltage

4000 V

Weight

1.3lbs 589.7g

HTS Kodu

8504.31.40.35

Fabrika Tedarik Süresi

18 Weeks

Physical Dimension

71.4mm X 47.6mm X 58.7mm

Output Current1

2 A

Yayın Yılı

2009

Voltage Secondary Full Load

Parallel 6.3V Series 12.6V

Onay Kuruluşu

UL; CSA; VDE

Terminal Stili

Solder, Quick Connect

Çalışma Sıcaklığı

-55°C ~ 125°C

Depth

10.141

Primary Rating

DUAL 115V

Nominal Gerilim

25 V

Primary Windings

Dual

REACH Uyumluluk Kodu

unknown

Parça Durumu

Active

Output Voltage2

6.3V

Kılıf / Paket

2917 (7343 Metric)

Output Power

25W

Output Voltage1

6.3V

Montaj Tipi

Chassis Mount

Boyut / Ölçü

71.40mm Lx54.40mm W

Manufacturer Series

A41

Seri

All-4-One™

Terminal

Solder

Transformer Type

SPLIT BOBBIN POWER TRANSFORMER

Manufacturer Size Code

E

Voltage Primary

115V 230V

Center Tap

No

Uzunluk

71.4mm
