3RT20381AR60

Teknik Özellikler

Max Temperature

+60°C

Dim

(W x H x D) 55 x 114 x 130 mm

Yükseklik

114mm

Montaj Tipi

Chassis Mount, DIN Rail

Connections

Screws

Nominal Voltage

690V AC

Özellikler

Auxiliary Contacts

Rated Operation Current Ie At Ac4400 V

55A

Rated Operation Power At Ac3400 V

37kW

Power Rating

37 kW

Rated Operation Current Ie At Ac1400 V

90A

Coil Power

188VA

Temel Ürün No

3RT2038

Operate Time

80 ms

Rohscompliant

Yes

Function

Reversing

No Of Pins

3-pin

Number Of Auxiliary Contacts As Normally Closed Contact

1

Ürün Durumu

Active

Seri

SIRIUS

Kontak Formu

3PST-NO (3 Form A)

Switching Voltage

690VAC - Max

Çalışma Sıcaklığı

-25°C ~ 60°C

Contact Type

3 makers

Tip

S2

Min Temperature

-25°C

Range

SIRIUS

Release Time

18 ms

Number Of Poles

3

Depth

130mm

Number Of Normally Open Contacts As Main Contact

3

Terminal Stili

Screw Terminal

Rated Operation Current Ie At Ac3400 V

80A

Paket

Box

Contact Rating Current

80 A

Ip Rating

IP20

Genişlik

55mm

Durability

1000 0000

Number Of Auxiliary Contacts As Normally Open Contact

1

Content

1pc(s)
