3RT20182XF410LA2

Teknik Özellikler

Dim

(W x H) 45 mm x 70 mm

Terminal Stili

Spring Terminal

Çalışma Sıcaklığı

-40°C ~ 70°C

Ürün Durumu

Active

Content

1pc(s)

Rated Operation Current Ie At Ac1400 V

22A

Contact Type

3 makers

Yükseklik

70mm

Number Of Auxiliary Contacts As Normally Open Contact

1

Rated Operation Current Ie At Ac3400 V

16A

Rated Operation Current Ie At Ac4400 V

11.5A

Genişlik

45mm

Operate Time

70 ms

Number Of Normally Closed Contacts As Main Contact

0

Coil Power

4.5W

Nominal Voltage

690V AC

Type Of Electrical Connection Of Main Circuit

Spring clamp connection

Contact Rating Current

16 A

Rated Operation Power At Ac3400 V

7.5kW

Kontak Formu

3PST-NO (3 Form A)

Paket

Bulk

Seri

SIRIUS

Auxiliary Contact Type

1 maker

Rated Operation Power At Ac4400 V

5.5kW

Number Of Normally Open Contacts As Main Contact

3

Montaj Tipi

Chassis Mount, DIN Rail

Connections

Spring-loaded connector

Rated Operation Power Nema

7.355

Rohscompliant

Yes

Modular Version

Yes

Tip

S00

Release Time

45 ms

Coil Voltage

72 ~ 125VDC

Durability

3000 0000

Switching Voltage

690VAC - Max

Rated Control Supply Voltage At Dc

72 - 125

No Of Pins

3-pin

Voltage Type For Actuating

DC
