CG30.6101.151

Teknik Özellikler

Housing Material

Thermoplastic

Gender

Male

Maks. Çalışma Sıcaklığı

85°C

Voltage Rated Dc

250V

Fuse

Yes

Voltage Rated Ac

125V

Akım Değeri

4A

Uzunluk

30mm

Contact Finish Mating

TIN/TIN COPPER

Min. Çalışma Sıcaklığı

-25°C

Connector Style

IEC 320-C14

Kurşunsuz Kodu

yes

Weight

92.999987g

Max Current Rating

4A

Option

GENERAL PURPOSE

RoHS Durumu

ROHS3 Compliant

Depth

69mm

Coupling Type

SNAP

Switch Features

Switch On-Off

Flammability Rating

UL94 V-0

Terminal

Quick Connect - 0.189 (4.8mm)

Voltageiec

250VAC

Akım

4A

Shell Material

POLYETHYLENE

Din Conformance

NO

Accomodates A Fuse

Yes (Fuse Not Included)

Fabrika Tedarik Süresi

10 Weeks

Number Of Ports

1

Connector Type

Receptacle, Male Blades - Module

Total Number Of Contacts

3

ECCN Kodu

EAR99

Fuse Holder Drawer

Drawer Sold Separate

Nem Hassasiyeti (MSL)

Vendor Undefined

Max Voltage Rating Ac

250V

Mil Conformance

NO

Ingress Protection

IP40

Iec Conformance

YES

Panel Cutout Dimensions

Rectangular - 28.50mm x 81.00mm

Özellikler

Voltage Selector

Orientation

Straight
