5008.0111

Teknik Özellikler

Mil Conformance

NO

Parça Durumu

Active

Max Voltage Rating Ac

250V

RoHS Durumu

ROHS3 Compliant

Housing Material

Thermoplastic

Onay Kuruluşu

cULus, ENEC

Material Flammability Rating

UL94 V-0

Orientation

Straight

Ingress Protection

IP40

Genişlik

37mm

Option

GENERAL PURPOSE

Montaj Tipi

Panel Mount, Flange

Panel Cutout Dimensions

Rectangular - 20.20mm x 16.00mm

Connector Style

IEC 320-C8, Non-Polarized

Din Conformance

NO

Voltage Rated Ac

250V

Max Current Rating

1A

Weight

17.338994g

Maks. Çalışma Sıcaklığı

85°C

Voltageiec

250VAC

Voltage Rated Dc

250V

Montaj

Flanges, Panel, Screw

Nem Hassasiyeti (MSL)

Vendor Undefined

Connector Type

Receptacle, Male Pins

Ambalaj

Bulk

Coupling Type

SNAP

Terminal

Quick Connect - 0.189 (4.8mm)

Fabrika Tedarik Süresi

12 Weeks

Akım

1A

Yükseklik

18mm

Mating Information

MULTIPLE MATING PARTS AVAILABLE

ECCN Kodu

EAR99

Gender

Receptacle

Number Of Ports

1

Filter Type

Filtered (EMI, RFI) - Commercial, Medical

Total Number Of Contacts

2

Min. Çalışma Sıcaklığı

-25°C

Shell Material

POLYETHYLENE

Kılıf / Paket

Module

Flammability Rating

UL94 V-0
