5003.1431.1

Teknik Özellikler

Seri

5003

Panel Cutout Dimensions

Rectangular - 29.40mm x 21.50mm

Connector Style

Special - AMP MATE-N-LOK or Molex MLX

Terminal

Quick Connect - 0.250 (6.3mm)

Filter Type

Filtered (EMI, RFI) - Commercial

Voltage Rated Dc

125V

Material Flammability Rating

UL94 V-0

Genişlik

32.6mm

Nominal Gerilim

125V

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Flammability Rating

UL94 V-0

Yükseklik

24.6mm

Panel Thickness

0.031 ~ 0.079 0.79mm ~ 2.00mm

Additional Feature

STANDARDS: UL 94V-0; VDE, QUICK CONNECT

Akım Değeri

15A

Shell Material

METALLIC/STEEL

Kılıf / Paket

Module

Max Current Rating

15A

Onay Kuruluşu

cULus, ENEC

Iec Conformance

NO

Max Voltage Rating Ac

125V

Option

GENERAL PURPOSE

Fabrika Tedarik Süresi

9 Weeks

Voltageiec

125VDC

Number Of Ports

1

ECCN Kodu

EAR99

Housing Material

Thermoplastic

Nem Hassasiyeti (MSL)

Vendor Undefined

Akım

10A

Connector Type

Receptacle, Male Pins

Orientation

Straight

Total Number Of Contacts

3

RoHS Durumu

ROHS3 Compliant

Accomodates A Fuse

No

Din Conformance

NO

Parça Durumu

Active

Maks. Çalışma Sıcaklığı

85°C

Shell Finish

TIN

Min. Çalışma Sıcaklığı

-25°C

Depth

62mm
