Adet bazlı fiyat
- 1+ adet$32.97
- 10+ adet$31.10
- 100+ adet$29.34
- 500+ adet$27.68
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Color Actuatorcap
- Clear (White Filter/Diffuser)
- Pozisyon Sayısı
- 2
- Contact Currentacmax
- 5A
- Çalışma Sıcaklığı
- -25°C~85°C
- Circuit
- SPDT
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- Electricallife
- 200,000 Cycles
- ECCN Kodu
- EAR99
- Yükseklik
- 38.1mm
- Contact Materials
- Silver
- Contact Voltage Rating Ac
- 250V
- Switch Function
- On-Mom
- Genişlik
- 76.2mm
- Panel Cutout Dimensions
- Circular - 19.10mm Dia
- HTS Kodu
- 8536.50.70.00
- Actuator Travel
- 0.9906 mm
- Uzunluk
- 50.8mm
- Ambalaj
- Bulk
- Özellikler
- Ceramic Actuator
- Max Voltage Rating Ac
- 250V
- Operating Force
- 4.5 N
- RoHS Durumu
- ROHS3 Compliant
- Illumination Type
- Illuminated, LED
- Contact Voltage Rating Dc
- 125V
- Voltage Rated Ac
- 125V
- Montaj Tipi
- Panel Mount, Front
- Terminal
- Quick Connect
- Illumination Voltage Nominal
- 24VDC
- Tip
- Anti-Vandal, Illuminated
- Nem Hassasiyeti (MSL)
- Vendor Undefined
- Kılıf / Paket
- Ceramic
- Mechanical Life
- 1,500,000 Cycles
- Akım Değeri
- 5A
- Renk
- Blue
- Seri
- MSM CS
- Ingress Protection
- IP40
- Illumination Type Color
- LED, Blue
- Packing Method
- BOX
- Contact Resistance
- 0.03mOhm
- Housing Material
- Stainless Steel
