Adet bazlı fiyat
- 1+ adet$37.19
- 10+ adet$35.09
- 100+ adet$33.10
- 500+ adet$31.23
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Materials
- Silver
- Contact Ac Max Rating R Load
- 5A@125VAC
- Yükseklik
- 31.75mm
- Contact Resistance
- 0.03mOhm
- ECCN Kodu
- EAR99
- Packing Method
- BOX
- Illumination Type Color
- LED, Green
- Electricallife
- 200,000 Cycles
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- Seri
- MSM CS
- Ingress Protection
- IP40
- Renk
- Green
- Çalışma Sıcaklığı
- -25°C~85°C
- Circuit
- SPDT
- Contact Currentacmax
- 5A
- Akım Değeri
- 5A
- Mechanical Life
- 1,500,000 Cycles
- Kılıf / Paket
- Ceramic
- Nem Hassasiyeti (MSL)
- Vendor Undefined
- Color Actuatorcap
- Clear (White Filter/Diffuser)
- Tip
- Anti-Vandal, Illuminated
- Illumination Voltage Nominal
- 24VDC
- Terminal
- Quick Connect
- Montaj Tipi
- Panel Mount, Front
- Voltage Rated Ac
- 125V
- Montaj
- Front, Panel
- Illumination Type
- Illuminated, LED
- Contact Current Rating
- 5A
- Parça Durumu
- Obsolete
- RoHS Durumu
- ROHS3 Compliant
- Operating Force
- 4.5 N
- Max Voltage Rating Ac
- 250V
- Özellikler
- Ceramic Actuator
- Actuator Type
- Round, Button, Flush
- Uzunluk
- 76.2mm
- Ambalaj
- Bulk
- Actuator Travel
- 0.9906 mm
- Weight
- 36.28739g
- Ratings
- IP40, IP65
- Current Rating Amps
- 5A AC
