Adet bazlı fiyat
- 1+ adet$21.02
- 10+ adet$19.83
- 100+ adet$18.71
- 500+ adet$17.65
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Terminal Stili
- Solder Lug
- Operating Force
- 3.7 N
- Voltage Rated Dc
- 48V
- Contact Current Rating
- 125mA
- Actuator Material
- Stainless Steel
- Pozisyon Sayısı
- 2
- Kılıf / Paket
- Metal
- Mechanical Life
- 1,000,000 Cycles
- Depth
- 21.5mm
- Fabrika Tedarik Süresi
- 15 Weeks
- Ratings
- Dust Tight, IP65, Water Resistant
- Parça Durumu
- Active
- Current Rating Amps
- 125mA DC
- Montaj Tipi
- Panel Mount, Front
- Illumination Type
- Illuminated, LED
- Reach Svhc
- No SVHC
- Nem Hassasiyeti (MSL)
- Vendor Undefined
- Radyasyon Dayanımı
- No
- Contact Plating
- Silver
- Contact Resistance
- 0.05mOhm
- RoHS Durumu
- ROHS3 Compliant
- Actuator Finish
- NICKEL
- Illumination Voltage Nominal
- 2.1VDC
- Illumination Color
- Green
- Body Height
- 8.8mm
- Throw Configuration
- SPDT, SPST
- Max Voltage Rating Dc
- 48V
- ECCN Kodu
- EAR99
- Illumination Type Color
- LED, Green
- Housing Material
- ZINC DIE CAST
- Circuit
- SPST-NO
- Ingress Protection
- IP65 - Dust Tight, Water Resistant
- Ambalaj
- Bulk
- Switch Function
- Off-Mom
- Terminal
- Solder
- Contact Ac Max Rating R Load
- A@VAC
- End Contact Material
- BRASS
- Akım Değeri
- 125mA
- Tip
- Anti-Vandal, Illuminated
- Uzunluk
- 21.5mm
