Adet bazlı fiyat
- 1+ adet$106.55
- 10+ adet$100.52
- 100+ adet$94.83
- 500+ adet$89.46
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Empedans
- 50Ohm
- Mil Conformance
- NO
- Adapter Series
- 7/16 to 7/16
- Fabrika Tedarik Süresi
- 13 Weeks
- Yayın Yılı
- 2015
- Fastening Type
- Threaded, Threaded
- JESD-609 Kodu
- e4
- Option
- GENERAL PURPOSE
- Additional Feature
- STANDARDS: DIN 47223; IEC 169-4
- Convert To Adapter End
- 7/16 Jack, Female Socket
- RoHS Durumu
- RoHS Compliant
- Din Conformance
- NO
- Convert From Adapter End
- 7/16 Jack, Female Socket
- Body Finish
- White Bronze
- Panel Mount
- YES
- Filter Feature
- NO
- Insertion Loss
- 0.05dB
- Adapter Type
- Jack to Jack
- Center Contact Plating
- Silver
- Iec Conformance
- NO
- Dielectric Material
- Polypropylene (PP)
- Mating Cycles
- 500
- Style
- Straight
- Frequencymax
- 7.5GHz
- Center Contact Material
- Beryllium Copper
- Operating Frequency Max
- 8.3GHz
- Center Gender
- Female to Female
- Includes
- 2 pcs - 1 Connector, 1 Nut
- Body Material
- Brass
- Contact Gender
- FEMALE-FEMALE
- Conversion Type
- Same Series
- Mounting Feature
- Bulkhead
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -45°C~85°C
- Montaj Tipi
- Panel Mount
- Vswr
- 1.47
