Adet bazlı fiyat
- 1+ adet$6.25
- 10+ adet$5.89
- 100+ adet$5.56
- 500+ adet$5.25
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Body Material
- Brass
- Mil Conformance
- NO
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Length Termination
- 0.098 inch
- Ambalaj
- Bulk
- Fastening Type
- Snap-On
- Shield Termination
- Solder
- Çalışma Sıcaklığı
- -55°C~155°C
- Filter Feature
- YES
- Mounting Feature
- Bulkhead - Front Side Nut
- Center Contact Plating
- Gold
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 13 Weeks
- Connector Type
- Plug, Male Pin
- Parça Durumu
- Active
- Yayın Yılı
- 2006
- Option
- GENERAL PURPOSE
- Mating Cycles
- 500
- Iec Conformance
- NO
- Insertion Loss
- 0.2 dB
- Empedans
- 50Ohm
- Operating Frequency Max
- 4GHz
- Contact Termination
- Solder Cup
- Connector Style
- SMB
- Reliability
- COMMERCIAL
- Özellikler
- Extended Insulation
- Contact Finish Mating
- NOT SPECIFIED
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Frequencymax
- 4GHz
- Body Depth
- 0.402 inch
- Includes
- 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
- Din Conformance
- NO
- RoHS Durumu
- RoHS Compliant
- Contact Materials
- NOT SPECIFIED
- Panel Mount
- YES
- Nominal Gerilim
- 250V
- Number Of Ports
- 1
- Total Number Of Contacts
- 1
- Montaj Tipi
- Panel Mount
- Contact Resistance
- 5mOhm
