Adet bazlı fiyat
- 1+ adet$45.14
- 10+ adet$42.58
- 100+ adet$40.17
- 500+ adet$37.90
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Frequencymax
- 4GHz
- Din Conformance
- NO
- Vswr
- 1.09
- RoHS Durumu
- RoHS Compliant
- Panel Mount
- NO
- Montaj Tipi
- Free Hanging (In-Line)
- Mating Cycles
- 500
- Iec Conformance
- NO
- Coupling Type
- SNAP-THREADED
- Operating Frequency Max
- 4GHz
- Empedans
- 50Ohm
- Insertion Loss
- 0.1 dB
- Center Contact Material
- Beryllium Copper
- Style
- Straight
- Çalışma Sıcaklığı
- -55°C~155°C
- Filter Feature
- NO
- Adapter Type
- Plug to Plug
- Center Contact Plating
- Gold
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 13 Weeks
- Convert To Adapter End
- SMA Plug, Male Pin
- Parça Durumu
- Active
- Yayın Yılı
- 2014
- Option
- GENERAL PURPOSE
- Body Material
- Beryllium Copper, Brass
- Mil Conformance
- NO
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Convert From Adapter End
- SMB Plug, Male Pin
- Conversion Type
- Between Series
- Adapter Series
- SMA to SMB
- Fastening Type
- Snap-On, Threaded
- Center Gender
- Male to Male
- Kılıf / Paket
- SMA
