Adet bazlı fiyat
- 1+ adet$39.38
- 10+ adet$37.15
- 100+ adet$35.05
- 500+ adet$33.07
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Style
- Straight
- Frequencymax
- 4GHz
- HTS Kodu
- 8536.69.80.00
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Coupling Type
- SNAP-THREADED
- Center Gender
- Female to Male
- Din Conformance
- NO
- Conversion Type
- Between Series
- Montaj Tipi
- Free Hanging (In-Line)
- Iec Conformance
- NO
- Center Contact Plating
- Gold
- Adapter Series
- SMA to SMB
- Adapter Type
- Plug to Jack
- Additional Feature
- CAPTIVATED CENTER CONTACT
- Filter Feature
- NO
- ECCN Kodu
- EAR99
- Mil Conformance
- NO
- Mating Cycles
- 500
- Panel Mount
- NO
- Convert From Adapter End
- SMB Jack, Female Socket
- Kılıf / Paket
- SMA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Fastening Type
- Snap-On, Threaded
- Convert To Adapter End
- SMA Plug, Male Pin
- Operating Frequency Max
- 4GHz
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Yayın Yılı
- 2014
- Direnç
- 59.132kOhm
- Vswr
- 1.09
- Option
- GENERAL PURPOSE
- Empedans
- 50Ohm
- Fabrika Tedarik Süresi
- 13 Weeks
- Body Material
- Beryllium Copper
- Insertion Loss
- 0.1 dB
- Çalışma Sıcaklığı
- -55°C~155°C
- RoHS Durumu
- RoHS Compliant
- Center Contact Material
- Beryllium Copper
