Adet bazlı fiyat
- 1+ adet$32.25
- 10+ adet$30.43
- 100+ adet$28.70
- 500+ adet$27.08
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Finish Mating
- NOT SPECIFIED
- HTS Kodu
- 8536.69.80.00
- Frequencymax
- 4GHz
- Style
- Straight
- Din Conformance
- NO
- Conversion Type
- Same Series
- Montaj Tipi
- Free Hanging (In-Line)
- Center Gender
- Female to Female
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Center Contact Plating
- Gold
- Iec Conformance
- NO
- Filter Feature
- NO
- Additional Feature
- CAPTIVATED CENTER CONTACT
- Adapter Series
- SMB to SMB
- Adapter Type
- Jack to Jack
- ECCN Kodu
- EAR99
- Mil Conformance
- NO
- Convert From Adapter End
- SMB Jack, Female Socket
- Mating Cycles
- 500
- Panel Mount
- NO
- Convert To Adapter End
- SMB Jack, Female Socket
- Fastening Type
- Snap-On, Snap-On
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Frequency Max
- 4GHz
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Option
- GENERAL PURPOSE
- Yayın Yılı
- 2014
- Vswr
- 1.2
- Fabrika Tedarik Süresi
- 13 Weeks
- Empedans
- 50Ohm
- Insertion Loss
- 0.2 dB
- Body Material
- Brass
- RoHS Durumu
- RoHS Compliant
- Çalışma Sıcaklığı
- -55°C~155°C
- Center Contact Material
- Beryllium Copper
