Adet bazlı fiyat
- 1+ adet$50.17
- 10+ adet$47.33
- 100+ adet$44.65
- 500+ adet$42.13
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Din Conformance
- NO
- Additional Feature
- INSERTION LOSS MAX AND VSWR MAX AT: 4 GHZ, CAPTIVATED CENTER CONTACT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Center Contact Material
- Beryllium Copper
- HTS Kodu
- 8536.69.80.00
- Reliability
- COMMERCIAL
- Convert From Adapter End
- TNC Plug, Male Pin
- Panel Mount
- NO
- Filter Feature
- NO
- Iec Conformance
- NO
- Convert To Adapter End
- SMA Jack, Female Socket
- Fastening Type
- Threaded, Threaded
- Empedans
- 50Ohm
- Montaj Tipi
- Free Hanging (In-Line)
- Option
- GENERAL PURPOSE
- Yayın Yılı
- 2014
- JESD-609 Kodu
- e4
- Adapter Series
- SMA to TNC
- Center Contact Plating
- Gold
- Body Finish
- Gold, Nickel
- Operating Frequency Max
- 10GHz
- Body Material
- Beryllium Copper, Brass
- Frequencymax
- 10GHz
- Conversion Type
- Between Series
- Center Gender
- Female to Male
- RoHS Durumu
- RoHS Compliant
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Adapter Type
- Plug to Jack
- Parça Durumu
- Active
- Coupling Type
- THREADED-THREADED
- Style
- Straight
- ECCN Kodu
- EAR99
- Insertion Loss
- 0.05dB
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Mating Cycles
- 500
- Vswr
- 1.08
- Mil Conformance
- NO
- Fabrika Tedarik Süresi
- 13 Weeks
- Çalışma Sıcaklığı
- -65°C~165°C
