Teknik Özellikler
- Direnç
- 53.503kOhm
- Mating Cycles
- 500
- Fabrika Tedarik Süresi
- 13 Weeks
- Yayın Yılı
- 2013
- Style
- Straight
- Empedans
- 50Ohm
- Adapter Series
- N to N
- Mounting Feature
- Bulkhead
- Convert From Adapter End
- N Jack, Female Socket
- Parça Durumu
- Active
- Insertion Loss
- 0.1 dB
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Includes
- 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
- RoHS Durumu
- RoHS Compliant
- Additional Feature
- INSERTION LOSS MAX AT: 9 GHZ
- Conversion Type
- Same Series
- Convert To Adapter End
- N Jack, Female Socket
- Adapter Type
- Jack to Jack
- Center Contact Plating
- Gold
- Vswr
- 1.17
- Mil Conformance
- NO
- Option
- GENERAL PURPOSE
- Contact Finish Mating
- NOT SPECIFIED
- Çalışma Sıcaklığı
- -45°C~85°C
- Filter Feature
- NO
- Fastening Type
- Threaded, Threaded
- Gender
- Female to Female
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Iec Conformance
- NO
- Center Contact Material
- Bronze
- Panel Mount
- NO
- Body Finish
- White Bronze
- Din Conformance
- NO
- Body Material
- Brass
- Montaj Tipi
- Panel Mount
- Frequencymax
- 11GHz
- Center Gender
- Female to Female
- Operating Frequency Max
- 11GHz
- Reliability
- COMMERCIAL
