Adet bazlı fiyat
- 1+ adet$47.90
- 10+ adet$45.18
- 100+ adet$42.63
- 500+ adet$40.21
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Conversion Type
- Between Series
- Convert To Adapter End
- TNC Jack, Female Socket
- Adapter Type
- Jack to Jack
- RoHS Durumu
- RoHS Compliant
- Additional Feature
- INSERTION LOSS MAX AT: 4 GHZ
- Parça Durumu
- Active
- Convert From Adapter End
- N Jack, Female Socket
- Insertion Loss
- 0.05dB
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Mating Cycles
- 500
- Fabrika Tedarik Süresi
- 13 Weeks
- Yayın Yılı
- 2015
- Style
- Straight
- Empedans
- 50Ohm
- Adapter Series
- N to TNC
- Frequencymax
- 10GHz
- Center Gender
- Female to Female
- Operating Frequency Max
- 10GHz
- Iec Conformance
- NO
- Center Contact Material
- Beryllium Copper
- Panel Mount
- NO
- Body Finish
- White Bronze
- Din Conformance
- NO
- Body Material
- Brass
- Montaj Tipi
- Free Hanging (In-Line)
- Mil Conformance
- NO
- Option
- GENERAL PURPOSE
- Çalışma Sıcaklığı
- -55°C~155°C
- Contact Finish Mating
- NOT SPECIFIED
- Filter Feature
- NO
- Fastening Type
- Threaded, Threaded
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Center Contact Plating
- Gold
- Vswr
- 1.5
