Adet bazlı fiyat
- 1+ adet$35.26
- 10+ adet$33.26
- 100+ adet$31.38
- 500+ adet$29.61
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mil Conformance
- NO
- Empedans
- 50Ohm
- Option
- GENERAL PURPOSE
- Adapter Series
- BNC to N
- Frequencymax
- 10GHz
- Body Finish
- White Bronze
- Center Contact Plating
- Gold
- Parça Durumu
- Active
- Insertion Loss
- 0.10dB
- Body Material
- Brass
- Contact Finish Mating
- NOT SPECIFIED
- Çalışma Sıcaklığı
- -55°C~155°C
- Conversion Type
- Between Series
- Fastening Type
- Bayonet Lock, Threaded
- Mating Cycles
- 500
- Vswr
- 1.29
- Operating Frequency Max
- 10GHz
- RoHS Durumu
- RoHS Compliant
- Coupling Type
- BAYONET-THREADED
- Center Gender
- Female to Female
- Yayın Yılı
- 2013
- Iec Conformance
- NO
- Style
- Straight
- Convert To Adapter End
- BNC Jack, Female Socket
- Fabrika Tedarik Süresi
- 13 Weeks
- Montaj Tipi
- Free Hanging (In-Line)
- Filter Feature
- NO
- Adapter Type
- Jack to Jack
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Center Contact Material
- Beryllium Copper
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Convert From Adapter End
- N Jack, Female Socket
- Direnç
- 53.151kOhm
- Din Conformance
- NO
- Gender
- Female to Female
- Panel Mount
- NO
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
