Adet bazlı fiyat
- 1+ adet$40.38
- 10+ adet$38.09
- 100+ adet$35.93
- 500+ adet$33.90
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Iec Conformance
- NO
- Yayın Yılı
- 2008
- Mil Conformance
- NO
- Çalışma Sıcaklığı
- -55°C~155°C
- Adapter Type
- Plug to Jack
- Frequencymax
- 10GHz
- Adapter Series
- BNC to N
- Empedans
- 50Ohm
- Mating Cycles
- 500
- Contact Gender
- MALE-FEMALE
- Style
- Straight
- Filter Feature
- NO
- Insertion Loss
- 0.16 dB
- Contact Finish Mating
- NOT SPECIFIED
- Convert From Adapter End
- BNC Plug, Male Pin
- RoHS Durumu
- RoHS Compliant
- Din Conformance
- NO
- Vswr
- 1.11
- Convert To Adapter End
- N Jack, Female Socket
- HTS Kodu
- 8536.69.80.00
- Body Finish
- White Bronze
- Panel Mount
- NO
- Parça Durumu
- Active
- Center Contact Plating
- Gold
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Free Hanging (In-Line)
- Center Gender
- Female to Male
- Fabrika Tedarik Süresi
- 13 Weeks
- Body Material
- Brass
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Fastening Type
- Bayonet Lock, Threaded
- Option
- GENERAL PURPOSE
- ECCN Kodu
- EAR99
- Conversion Type
- Between Series
- Center Contact Material
- Beryllium Copper
- Operating Frequency Max
- 10GHz
- Coupling Type
- BAYONET-THREADED
