Adet bazlı fiyat
- 1+ adet$15.70
- 10+ adet$14.81
- 100+ adet$13.97
- 500+ adet$13.18
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Center Contact Plating
- Gold
- JESD-609 Kodu
- e4
- Montaj Tipi
- Free Hanging (In-Line)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reliability
- COMMERCIAL
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Fabrika Tedarik Süresi
- 13 Weeks
- Center Gender
- Female to Female
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Body Material
- Brass
- Fastening Type
- Bayonet Lock, Bayonet Lock
- Conversion Type
- Same Series
- ECCN Kodu
- EAR99
- Option
- GENERAL PURPOSE
- Operating Frequency Max
- 10GHz
- Center Contact Material
- Bronze
- Çalışma Sıcaklığı
- -45°C~85°C
- Mil Conformance
- NO
- Yayın Yılı
- 2008
- Iec Conformance
- NO
- Frequencymax
- 10GHz
- Adapter Type
- Jack to Jack
- Empedans
- 50Ohm
- Adapter Series
- BNC to BNC
- Contact Gender
- FEMALE-FEMALE
- Mating Cycles
- 500
- Direnç
- 51.101kOhm
- Additional Feature
- INSERTION LOSS AND VSWR MAX AT: 6 GHZ
- RoHS Durumu
- RoHS Compliant
- Convert From Adapter End
- BNC Jack, Female Socket
- Insertion Loss
- 0.16 dB
- Filter Feature
- NO
- Style
- Straight
- Din Conformance
- NO
- HTS Kodu
- 8536.69.80.00
- Convert To Adapter End
- BNC Jack, Female Socket
- Vswr
- 1.22
- Parça Durumu
- Active
- Panel Mount
- NO
- Body Finish
- White Bronze
