Teknik Özellikler
- Contact Gender
- MALE-MALE
- Panel Mount
- NO
- Mating Cycles
- 500
- Frequencymax
- 6GHz
- Adapter Type
- Plug to Plug
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Additional Feature
- STANDARD: MIL-STD-202, CAPTIVE CENTER CONTACT
- Din Conformance
- NO
- Mil Conformance
- YES
- Iec Conformance
- NO
- Convert From Adapter End
- SMC Plug, Male Pin
- Fabrika Tedarik Süresi
- 13 Weeks
- Center Contact Plating
- Gold
- Fastening Type
- Snap-On, Threaded
- Contact Finish Mating
- NOT SPECIFIED
- Body Material
- Beryllium Copper, Brass
- RoHS Durumu
- RoHS Compliant
- Center Gender
- Male to Male
- Operating Frequency Max
- 6GHz
- Center Contact Material
- Beryllium Copper
- Çalışma Sıcaklığı
- -55°C~155°C
- Insertion Loss
- 0.24 dB
- HTS Kodu
- 8536.69.80.00
- Convert To Adapter End
- SMA Plug, Male Pin
- Style
- Straight
- ECCN Kodu
- EAR99
- Adapter Series
- SMA to SMC
- Montaj Tipi
- Free Hanging (In-Line)
- Filter Feature
- NO
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Parça Durumu
- Active
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Vswr
- 1.29
- Option
- GENERAL PURPOSE
- Conversion Type
- Between Series
- Empedans
- 50Ohm
