Adet bazlı fiyat
- 1+ adet$68.90
- 10+ adet$65.00
- 100+ adet$61.32
- 500+ adet$57.85
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Mil Conformance
- YES
- Additional Feature
- STANDARD: MIL-STD-348A, IEC 60169-15
- Body Material
- Beryllium Copper
- Adapter Type
- Plug to Jack
- Montaj Tipi
- Free Hanging (In-Line)
- Iec Conformance
- YES
- Din Conformance
- NO
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Center Contact Material
- Beryllium Copper, Brass
- Center Gender
- Female to Male
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Style
- T-Shape
- Panel Mount
- NO
- Contact Finish Mating
- NOT SPECIFIED
- Conversion Type
- Same Series
- Option
- GENERAL PURPOSE
- Frequencymax
- 12.4GHz
- Operating Frequency Max
- 12.4GHz
- Yayın Yılı
- 2016
- Empedans
- 50Ohm
- Coupling Type
- THREADED-THREADED-THREADED
- Mating Cycles
- 500
- RoHS Durumu
- RoHS Compliant
- Adapter Series
- SMA to SMA, Dual
- Çalışma Sıcaklığı
- -65°C~165°C
- Convert From Adapter End
- SMA Plug, Male Pin
- Filter Feature
- NO
- Fastening Type
- Threaded, Threaded
- Center Contact Plating
- Gold
- Convert To Adapter End
- SMA Jack, Female Socket (2)
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 13 Weeks
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
