Adet bazlı fiyat
- 1+ adet$20.79
- 10+ adet$19.61
- 100+ adet$18.50
- 500+ adet$17.45
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Additional Feature
- CAPTIVE CENTER CONTACT
- Mil Conformance
- NO
- Body Material
- Beryllium Copper
- Montaj Tipi
- Free Hanging (In-Line), Right Angle
- Adapter Type
- Plug to Jack
- Iec Conformance
- NO
- Din Conformance
- NO
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Center Gender
- Female to Male
- Center Contact Material
- Beryllium Copper
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Panel Mount
- NO
- Style
- Right Angle
- Contact Finish Mating
- NOT SPECIFIED
- Option
- GENERAL PURPOSE
- Conversion Type
- Same Series
- Operating Frequency Max
- 18GHz
- Frequencymax
- 18GHz
- Reliability
- COMMERCIAL
- Yayın Yılı
- 2016
- Insertion Loss
- 0.17 dB
- Empedans
- 50Ohm
- Mating Cycles
- 500
- RoHS Durumu
- RoHS Compliant
- Adapter Series
- SMA to SMA
- Çalışma Sıcaklığı
- -65°C~165°C
- Convert From Adapter End
- SMA Plug, Male Pin
- Vswr
- 1.25
- Filter Feature
- NO
- Center Contact Plating
- Gold
- Fastening Type
- Threaded, Threaded
- Convert To Adapter End
- SMA Jack, Female Socket
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 13 Weeks
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
