Adet bazlı fiyat
- 1+ adet$58.22
- 10+ adet$54.93
- 100+ adet$51.82
- 500+ adet$48.88
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Active
- Convert To Adapter End
- SMA Plug, Male Pin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 13 Weeks
- Vswr
- 1.14
- Convert From Adapter End
- RP-SMA Jack, Male Pin
- Fastening Type
- Threaded, Threaded
- Center Contact Plating
- Gold
- Filter Feature
- NO
- Çalışma Sıcaklığı
- -65°C~165°C
- Adapter Series
- SMA to RP-SMA
- Mating Cycles
- 500
- RoHS Durumu
- RoHS Compliant
- Option
- GENERAL PURPOSE
- Conversion Type
- Between Series
- Empedans
- 50Ohm
- Insertion Loss
- 0.21 dB
- Yayın Yılı
- 2014
- Operating Frequency Max
- 18GHz
- Frequencymax
- 18GHz
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- HTS Kodu
- 8536.69.80.00
- Contact Finish Mating
- NOT SPECIFIED
- Panel Mount
- NO
- Style
- Straight
- ECCN Kodu
- EAR99
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Din Conformance
- NO
- Iec Conformance
- NO
- Center Contact Material
- Brass
- Center Gender
- Male to Male
- Body Material
- Beryllium Copper
- Mil Conformance
- NO
- Additional Feature
- CAPTIVE CENTER CONTACT
- Montaj Tipi
- Free Hanging (In-Line)
- Adapter Type
- Plug to Jack
