Adet bazlı fiyat
- 1+ adet$29.40
- 10+ adet$27.74
- 100+ adet$26.17
- 500+ adet$24.68
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Fabrika Tedarik Süresi
- 13 Weeks
- Yayın Yılı
- 2016
- Empedans
- 50Ohm
- HTS Kodu
- 8536.69.80.00
- Filter Feature
- NO
- Çalışma Sıcaklığı
- -55°C~155°C
- Din Conformance
- NO
- Center Contact Material
- Beryllium Copper
- Mil Conformance
- NO
- Center Gender
- Female to Female
- Option
- GENERAL PURPOSE
- Fastening Type
- Threaded, Threaded
- Insertion Loss
- 0.1 dB
- Body Finish
- Gold, Nickel
- Convert From Adapter End
- SMA Jack, Female Socket
- Parça Durumu
- Active
- Vswr
- 1.31
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Montaj Tipi
- Panel Mount
- RoHS Durumu
- RoHS Compliant
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Adapter Series
- SMA to N
- Panel Mount
- YES
- ECCN Kodu
- EAR99
- Body Material
- Beryllium Copper, Brass
- Frequencymax
- 11GHz
- Conversion Type
- Between Series
- Mating Cycles
- 500
- Adapter Type
- Jack to Jack
- Style
- Straight
- Center Contact Plating
- Gold
- Iec Conformance
- NO
- Mounting Feature
- Flange
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Convert To Adapter End
- N Jack, Female Socket
- Operating Frequency Max
- 11GHz
