Adet bazlı fiyat
- 1+ adet$45.84
- 10+ adet$43.24
- 100+ adet$40.79
- 500+ adet$38.49
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- JESD-609 Kodu
- e4
- Convert To Adapter End
- BNC Plug, Male Pin
- Operating Frequency Max
- 10GHz
- Center Contact Plating
- Gold
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Iec Conformance
- NO
- Conversion Type
- Between Series
- Frequencymax
- 10GHz
- Body Material
- Beryllium Copper, Brass
- Style
- Straight
- Additional Feature
- CAPTIVE CENTER CONTACT
- Mating Cycles
- 500
- Adapter Type
- Plug to Jack
- Reliability
- COMMERCIAL
- Panel Mount
- NO
- ECCN Kodu
- EAR99
- Montaj Tipi
- Free Hanging (In-Line)
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Vswr
- 1.1
- Parça Durumu
- Active
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Adapter Series
- BNC to SMA
- RoHS Durumu
- RoHS Compliant
- Insertion Loss
- 0.13 dB
- Fastening Type
- Bayonet Lock, Threaded
- Option
- GENERAL PURPOSE
- Coupling Type
- BAYONET-THREADED
- Kurşunsuz Kodu
- yes
- Convert From Adapter End
- SMA Jack, Female Socket
- Center Contact Material
- Beryllium Copper
- Din Conformance
- NO
- Çalışma Sıcaklığı
- -55°C~155°C
- Center Gender
- Female to Male
- Mil Conformance
- NO
- Yayın Yılı
- 2007
- Fabrika Tedarik Süresi
- 13 Weeks
- Empedans
- 50Ohm
- HTS Kodu
- 8536.69.80.00
- Filter Feature
- NO
