Adet bazlı fiyat
- 1+ adet$15.14
- 10+ adet$14.28
- 100+ adet$13.47
- 500+ adet$12.71
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Reliability
- COMMERCIAL
- Panel Mount
- NO
- Conversion Type
- Same Series
- Body Material
- Beryllium Copper, Brass
- Frequencymax
- 18GHz
- Additional Feature
- VSWR MAX AT 19 GHZ, CAPTIVATED CENTER CONTACT
- Style
- Straight
- Adapter Type
- Jack to Jack
- Mating Cycles
- 500
- Center Contact Plating
- Gold
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Iec Conformance
- NO
- Operating Frequency Max
- 18GHz
- Convert To Adapter End
- SMA Jack, Female Socket
- Rated Current Signal
- 1.2A
- Yayın Yılı
- 2007
- Fabrika Tedarik Süresi
- 13 Weeks
- Contact Finish Mating
- NOT SPECIFIED
- Filter Feature
- NO
- Empedans
- 50Ohm
- Kılıf / Paket
- SMA
- Center Contact Material
- Beryllium Copper
- Din Conformance
- NO
- Çalışma Sıcaklığı
- -55°C~155°C
- Center Gender
- Female to Female
- Mil Conformance
- NO
- Insertion Loss
- 0.13 dB
- Fastening Type
- Threaded, Threaded
- Option
- GENERAL PURPOSE
- Convert From Adapter End
- SMA Jack, Female Socket
- Montaj Tipi
- Free Hanging (In-Line)
- Parça Durumu
- Active
- Vswr
- 1.22
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Adapter Series
- SMA to SMA
- RoHS Durumu
- RoHS Compliant
