Teknik Özellikler
- Body Material
- Beryllium Copper, Brass
- Fabrika Tedarik Süresi
- 13 Weeks
- Mating Cycles
- 500
- Iec Conformance
- YES
- RoHS Durumu
- RoHS Compliant
- Yayın Yılı
- 2014
- Parça Durumu
- Active
- Mil Conformance
- NO
- Adapter Series
- N to MCS
- Conversion Type
- Between Series
- Empedans
- 50Ohm
- Contact Gender
- MALE-FEMALE
- Insulation Materials
- POLYTETRAFLUORO ETHYLENE
- Panel Mount
- NO
- Option
- GENERAL PURPOSE
- Convert To Adapter End
- N Jack, Female Socket
- HTS Kodu
- 8536.69.80.00
- Style
- Straight
- Din Conformance
- NO
- Filter Feature
- NO
- Center Contact Material
- Beryllium Copper
- Operating Frequency Max
- 6GHz
- Additional Feature
- STANDARD: IEC 60169-36
- Center Gender
- Female to Male
- Body Finish
- Gold, Nickel
- Convert From Adapter End
- MCX Plug, Male Pin
- Center Contact Plating
- Gold
- Vswr
- 1.2
- Çalışma Sıcaklığı
- -55°C~155°C
- Dielectric Material
- Polytetrafluoroethylene (PTFE)
- Adapter Type
- Plug to Jack
- Fastening Type
- Snap-On, Threaded
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Free Hanging (In-Line)
- Coupling Type
- SNAP-THREADED
- ECCN Kodu
- EAR99
- Insertion Loss
- 0.6 dB
- Frequencymax
- 6GHz
